Dormer construction requires proper structural review because a dormer changes the existing roof structure, creates new openings, and redirects loads through studs, headers, trimmer studs, walls, and foundations. If these elements are not checked correctly, the dormer may cause roof deflection, overstressed framing, permit review delays, or construction issues.

Project Overview

This example relates to a proposed double flat roof cold roof dormer. The structural review focused on the timber framing elements, including the dormer front wall, cheek wall, header members over openings, and jamb/trimmer studs supporting the headers.

The design used C24 timber, 2x6 studs at 406 mm centres, and a built-up header beam formed from two 2x6 C24 members. A Eurocode-based approach was adopted, using BS EN 1990 for design basis and combinations and BS EN 1995-1-1 for timber member design.

Design Basis And Loading

The calculation considered roof dead load, roof variable load, wall self-weight, and ultimate load combinations. The adopted roof design load was calculated using:

qd = 1.35Gk + 1.50Qk

This produced an ultimate roof design load of 2.31 kN/m². Roof reaction line loads were then calculated for the longer and shorter roof zones so the supporting wall studs and headers could be checked.

Common Stud Checks

The common wall studs were checked for axial compression. The front wall common stud compression stress was calculated as 0.27 N/mm², while the cheek wall common stud compression stress was calculated as 0.42 N/mm².

Both values were well below the adopted C24 compression design strength of 12.92 N/mm². This confirmed that the proposed 38 x 140 mm C24 studs at 406 mm centres were adequate for the adopted loading basis.

Header Beam Checks

The header beam was checked as a built-up section using two 2x6 C24 members acting together, giving an overall section size of 76 x 140 mm.

For the 1.70 m opening, the calculated bending stress was 6.88 N/mm², which was below the adopted bending design strength of 14.77 N/mm². The calculated shear stress was 0.57 N/mm², which was also below the adopted shear design strength of 2.46 N/mm².

Deflection was checked as well. The calculated deflection was 1.89 mm, which was less than the allowable L/360 limit of 4.72 mm.

The smaller 0.65 m opening was also checked and found to be adequate for bending and shear.

Jamb And Trimmer Stud Checks

The jamb/trimmer stud supporting the 1.70 m header was checked using the header end reaction. The calculated compression stress in one 2x6 trimmer stud was 0.76 N/mm², which was below the adopted compression design strength of 12.92 N/mm².

This confirmed that the proposed jamb/trimmer stud was adequate under the adopted assumptions.

Summary Of Results

The calculation confirmed that the front wall studs, cheek wall studs, header over the 1.70 m opening, header over the 0.65 m opening, and jamb/trimmer stud under the larger header were structurally adequate.
